LoRaWAN Gateway
The professional manufacturer of LoRa gateways has the characteristics of long distance, low power consumption, anti-interference, high sensitivity, and low cost. The lora wireless transmission technology is suitable for use in smart meter reading, smart oil fields, agricultural monitoring, industrial manufacturing, smart buildings and other fields.
Product Details
Product Description
UG65 is an industrial gateway based on LoRaWAN technology. It features Edge and Fog computing capabilities with Python programming, rich serial interface and free embedded NS, available in CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923 global frequency. Our LoRaWAN ecosystem partners include The Things Network (TTN), LORIOT, Ubidots, ChirpStack, IoThink Solutions, Orbiwise, LoRa Alliance and ThingWorx. The UG65 has been distributed to the dozens of regions and deployed in pilot use cases and LPWAN projects.
Quick Details of Milesight UG65 LoRaWAN Gateway
UG65 LoRaWAN Gateway | ||
Hardware | Processor | Quad-core 1.5 GHz, 64-bit ARM Cortex-A53 |
Memory | 512 MB DDR4 RAM | |
Ingress Protection | IP65 | |
Connectivity | Frequency Band | CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923 |
Channel | 8 | |
Wi-Fi | IEEE 802.11 b/g/n | |
Ethernet | 1 x 10/100/1000 Mbps | |
Network Server | Embedded | Yes |
3rd Party's | TTN, LORIOT, ThingWorx | |
Capabilities | Nodes Connection | Up to 2000 |
Radio Range | Up to 10 km | |
The IoT Cloud is a comprehensive cloud service provides unparalleled levels of vertical integration with LoRaWAN Gateway to link vertical, back-end applications to remote assets.
Detailed Images
Cloud
Partners
Success Story
Specifications
Model | UG65 |
Hardware | |
Processor | Quad-core 1.5 GHz, 64-bit ARM Cortex-A53 |
Memory | 512 MB DDR4 RAM |
Flash | 8 GB eMMC |
Software | |
Network Protocol | PPPoE, SNMP v1/v2c/v3, TCP, UDP, DHCP, DDNS,HTTP, HTTPS, DNS, ARP, SNTP, Telnet, SSH, MQTT, etc. |
VPN Tunnel | OpenVPN/IPsec/PPTP/L2TP/GRE/DMVPN |
Connectivity | |
Ethernet | 1 x 10/100/1000 Mbps |
Cellular (optional) | 1 x SIM Slot |
Wi-Fi (Optional) | IEEE 802.11 b/g/n/ac |
Console | 1 x Console (RJ45) |
GPS + GLONASS | Yes |
LoRaWAN | |
Channel | 8 |
Frequency Band | CN470/IN865/EU868/RU864/US915/AU915/KR920/AS923 |
Sensitivity | -140dBm Sensitivity @292bps |
Output Power | 27dBm Max |
Protocol | V1.0 Class A/Class C and V1.0.2 Class A/Class C |
Others | |
Operating Temp | -40°C to +70°C (-40℉ to +158℉) Reduced Cellular Performance Above 60°C |
Storage Temp | -40°C to +85°C (-40℉ to +185℉) |
Relative Humidity | 0% to 95% (non-condensing) at 25°C/77℉ |
Ingress Protection | IP65 |
Mounting | Desktop, Wall or DIN Rail Mounting |
Dimensions | 180 x 110 x 56.5 mm |
Certifications | RoHS, CE, FCC |
The LoRa gateway has a strong network conversion capability, LoRa to TCP/IP protocol. At the same time, it supports full Netcom, 4G, 3G, 2.5G and other full-line networks, providing customers with more options for project construction.
