Weather Stations

Three wind cup Integrated wind speed direction sensor Anemometer for weather station 4-20mA/RS485/Modbus

The integrated wind speed and direction sensor consists of a wind speed sensor and a wind direction sensor. The wind speed sensor adopts the traditional three-cup wind speed sensor structure, and the wind cup is made of carbon fibre material with high strength and good start-up.The wind direction sensor adopts a precision potentiometer and a low-inertia light metal wind vane to respond to the wind direction, with good dynamic characteristics.It can be widely used in meteorolo···

Product Details

The integrated wind speed and direction sensor consists of a wind speed sensor and a wind direction sensor.

The wind speed sensor adopts the traditional three-cup wind speed sensor structure, and the wind cup is made of carbon fibre material with high strength and good start-up.

The signal processing unit inside the cup can output the corresponding wind speed signal according to the user's needs. The wind direction sensor adopts a precision potentiometer and a low-inertia light metal wind vane to respond to the wind direction, with good dynamic characteristics.


Integrated wind speed and direction sensor application scenarios:

The product has the advantages of large measuring range, good linearity, strong resistance to lightning strikes, convenient observation, stability and reliability, etc.

It can be widely used in meteorology, marine, environment, airport, port, laboratory, industry and agriculture and transportation.

Integrated wind speed and direction sensor technical parameters:

Wind speed sensor

Measuring range: 0~45m/s, 0~70m/s optional

Accuracy: ±(0.3+0.03V)m/s (V: wind speed)

Discrimination rate:0.1m/s

Start wind speed: ≤0.8m/s

Product weight: 130 g

Product power consumption: 50 mW

Integrated wind speed direction sensor.png

Wind direction sensor

Measuring range: 0 to 360°

Resolution: 1°

Accuracy: ±3°

Start wind speed: ≤0.5m/s

Product weight: 210 g

Product power consumption: 5.5 mW

Cable rating: rated voltage: 300V , temperature rating: 80°C

Power supply: 5V/12V/24V

Wiring method: Voltage type: 4 wires, current type: 4 wires, RS-485 signal: 4 wires

Signal output: voltage type: 0-5V DC, current type: 4-20 mA

RS-485 signal: support ModBus protocol (baud rate 9600 can be set, address 0-255 can be set)

Material: metal shell, engineering carbon fibre airfoil and tailpiece, good strength, higher sensitivity

Working environment: Temperature -40℃~50℃ Humidity ≤100%RH

Protection class: IP45


One-piece wind speed and direction sensor installation:

When installing the sensor, please ensure that the wind direction sensor is on the top and the wind speed sensor is on the bottom, and that the sensor is installed in a vertical direction to the ground, there is a white fixing point on the wind direction sensor, please refer to the compass included with the product to keep the wind direction guide direction in line with the geographical south before use.

Troubleshooting :

   1、The wind vane rotation is not working, the hysteresis is big. May be due to long-term use There are foreign objects in the bearing or the lubricant is used up. Please fill the instrument oil from the upper bearing of the sensor or send the sensor back to the company for oil injection.  The oil should be injected from the upper bearing of the sensor or the sensor should be returned to the company.

   2. When the analogue output is used, the display shows a value of 0 or not in range. 2. When the analogue output is displayed, the display shows a value of 0 or not within range. It is possible that the collector is not getting the correct information due to a wiring problem. Check that the wiring is correct and secure. Please check that the wiring is correct and secure.

   3、If not for the above reasons, please contact the manufacturer.
